D-Box™ (V-mount Battery Side to Gold Mount Camera Side, Base Unit)

SKU 218900

UPC 702534256068

IN STOCK Complete purchase by 3pm CST and order will ship same business day.

WC Pro Power Plate available for an additional $150 by emailing info@woodencamera.com or making an order note.

D-Box (V-mount Battery Side to Gold Mount Camera Side, Base Unit) is great for converting Gold Mount specific cameras to V-Mount batteries. An example of this would be the VariCam LT which ships standard with a Gold Mount plate. This device would allow you to have power distribution and use V-Mount batteries. Power is passed though to D-Box and to camera.

D-Box (Power Distribution) allows for user selectable power outputs including 2 pin LEMO compatible connectors, 4 pin LEMO compatible connectors, 4 pin Hirose, 3 pin Fischer, D-Tap, and USB. Allows for up to 6 simultaneous outputs with a maximum draw of 3A per output (24V output is 1A max each) and 10A total draw limited by an easily accessible fuse. Left side panel opens to service fuse and to disconnect and remove connector panels.

Please Note: In addition to the digital or glass fuse governing the output panels of the D-box, his product contains a secondary fuse for the D-tap ports of the attached battery plate. This fuse is located in a fuse holder within the plate and replacements can be purchased here: F10A Fast Blow Fuse

Choose from any of the below (sold separately):
- 2 pin LEMO compatible connector
- 4 pin LEMO compatible connector
- 4 pin Hirose
- 3 pin Fischer
- D-Tap
- Blank

Connectors used in this assembly are not manufactured by LEMO or Fischer but are made to the same specifications and are LEMO and Fischer compatible.

Note: Slots 2 & 3 cannot both host D-Taps due to internal interference with one another. Please select D-Tap for one slot or the other. If you are looking for a D-Tap Breakout Cable, choose 1 to 4 D-Tap Splitter Cable

Weight: 610g (1.3 lbs)
Dimensions: 50.8 x 101.6 x 152.4 mm ( 2 x 4 x 6 in)
